The low bed semi trailer can satisfy the concentrated force, the anti bump, the distortion resistance and adopts  High Strength Steel Material. we use it to make sure our low bed Trailer  with a long service life and to avoid unnecessary maintenance.

Specification:

ADVANTAGE:

1.Our low bed trailer adopts high strength steel material , the yield strength of steel is more durable and stronger than ordinary steel, and its loading capacity is 5 times more the normal trailer .

2.The low bed trailer adopts 550mm main beam ,effectively increase 20% loading capacity than the normal trailer which uses 500mm main beam ,and ensure the main beam resistance to twisting forces, shock and bump, meet load requirements on different kinds of roads .

Overall Dimension: 10000(L)*2500(W)*3400(H)mm

Tare Weight: 7.5T

Pay Load: 60T

Suspension: Mechanical Suspension with 10-layers leaf spring

Side beam:160mm Channel Steel

Bottom Platform: 4mm Checkered Plate

King Pin: 3.5’’(90mm)

Landing Gear: Brand JOST

TIre:12.00R22.5*12pcs

Axles: 3 units of FUWA axles

Brake system: WABCO

Spare Wheel Rack: 1 pcs

Electric System: 24V, One Set 6-core Standard Cable

Tool Box: 1pc

Light: Tail lamp with turn signal,brake light & reflector,side lamp etc

Painting: Primer Coating, Top Painting, Wax Polishing

Color: yellow
